SAMES A3 HPA Automatic Airspray Spray Gun
The A3 compact automatic low pressure spray gun is recommended for touch-up & delicate work or when volume is an issue.
High transfer efficiency
Outstanding finish quality
High reliability
Performance
♦ Index knob adjustments of fluid output allow for precise output accuracy
♦ Fan width control for a finish quality & fan pattern optimization
♦ Precise machining of the air cap to give a perfect fan
Productivity
♦ A reduced overspray allows a fast ROI (Return on Investment) for products savings
♦ GL specific projectors for lines
Sustainability
♦ A reduced overspray allows a decrease in spray booth maintenance
♦ Brass nickel plated air cap provides high resistance to water-based materials
| Designation | Value |
|---|---|
| Maximum Air Pressure (bar) | 6 |
| Maximum Air Pressure (psi) | 87 |
| Recommended Air Pressure (bar) | 3 to 6 |
| Recommended Air Pressure (psi) | 43 to 87 |
| Trigger Air Pressure (bar) | 3 |
| Trigger Air Pressure (psi) | 43.5 |
| Designation | Part number | Max flowrate (cc/mn) | Max flowrate (gal/mn) | Nozzle size (in) | Nozzle size (mm) | Type | Fan width (cm) |
|---|---|---|---|---|---|---|---|
| A3 gun HPA 8PX | 135713014 | 200 | 0.052 | 0.31 | 0.8 | Flat spray pattern | 3-10 |
| A3 gun HPA 10PX | 135713011 | 300 | 0.79 | 0.39 | 1 | Flat spray pattern | 4-15 |
| A3 gun HPA 12PX | 135713012 | 450 | 0.118 | 0.47 | 1.2 | Flat spray pattern | 5-15 |
| A3 gun HPA 6GL | 135713017 | 180 | 0.047 | 0.23 | 0.6 | Round spray pattern | 0.4 - 2.5 |
| A3 gun HPA 10GL | 135713015 | 300 | 0.079 | 0.39 | 1 | Round spray pattern | 0.4 - 3 |
