SAMES 04D140 Diaphragm Pump 3.5:1
Minimum pulsation with short-stroke principle
Maximisation of service life
Minimal operating and maintenance costs
Performance
♦ High frequency operation up to 8 cycles/sec
♦ Minimal pulsation due to faster switching cycles of the valve and short stroke principle
Stalling free conception with bistabke latching valve
Productivity
High pressure output with internal transmission
Reversible design to facliltate the integration
Advanced soft seat design minimizes paint shearing
Sustainability
Wear free pneumatic ceramic valve
Short stroke diaphragm minimizing overstretching, resulting longer life span
♦ Compressed air savings up to 55% thanks to few tiny dead spots and compact design of the switching valve
| Designation | Value |
|---|---|
| Maximum Air Pressure (bar) | 6 |
| Maximum Air Pressure (psi) | 87 |
| Recommended Material Viscosity Range | 15 000 mPa |
| Fluid Output at 20 cycles / mn (gal/min) | 0.7 |
| Fluid Output at 20 cycles / mn (l/min) | 2.8 |
| Fluid Output at 60 cycles / mn (gal/min) | 2.2 |
