SAMES 01D100 Diaphragm Pump 1:1
Pulsation free with Regpro solution for high finishing results
Robust durable design
User friendly
Performance
Large 1/2 BSPP suction inlet to increase the suction power
Foot assembly for stable installation during application and maintenance
♦ PTFE diaphragms for standard application or PU diaphragms for abrasive materials application
Productivity
90° adjustable fluid inlet and outlet
New air distributor with protected seals and spring loaded to avoid stalling
♦ Compatible with water-based and solvent-based materials
♦ Minimum dead zone for better flushing and cleaning
Sustainability
Aluminum central body with impregnated resin to avoid corrosion
Robust construction: fluid collectors and flanges in polypropylene with 30% carbon fiber
♦ Low noise for more comfort of use
| Designation | Value |
|---|---|
| Maximum Air Pressure (bar) | 6 |
| Maximum Air Pressure (psi) | 87 |
| Fluid Output at 20 cycles / mn (gal/min) | 0.52 |
| Fluid Output at 20 cycles / mn (l/min) | 2 |
| Fluid Output at 60 cycles / mn (gal/min) | 1.58 |
| Fluid Output at 60 cycles / mn (l/min) | 6 |
