The Airmix® Xcite®+ manual paint spray gun delivers outstanding performance with unsurpassed finish quality for a quick payback. It is available in 3 pressure ranges: 120, 240 & 400 bar (1740-3480-5800psi) to meet every application.



Product savings & environmental protection



Unsurpassed atomization quality

Ergonomically designed for outstanding performance



Performance

Large tip selection with dedicated Xtra Fine Finish tips for water-based material with wide choice of flow rates and fan width patterns

Unsurpassed finishing quality and outstanding transfer efficiency with VX24 HVLP aircap

Built-in filter with high filtration capacity to avoid tip blockage and minimize pressure loss

Job repeatability with our selection of tips that are individually tested to guarantee a consistent pattern

Diffuser and deflector embedded to decrease the atomizing air consumption and improve atomization



Sustainability

Increased operator safety with trigger lock and aircap protection

Anodized body with laser engraving not affected by exposure to solvents

Construction built to last and compatible with all types of materials (even water-based with stainless steel fluid passage and Rulon® sealing)

Double seal technology to prevent aircap leakage and paint return on the air circuit



DesignationValue
Maximum Air Pressure (bar)6
Maximum Air Pressure (psi)87
Recommended Air Pressure (min) (bar)0.7
Recommended Air Pressure (min) (psi)11.6
Weight (g)579
Weight (oz)20
DesignationPart number
Xcite®+ gun 240B VX24 KHVLP AIRCAP & SWIVEL FITTING135732200
Xcite®+ gun 120B VX24 KHVLP AIRCAP W/O SWIVEL FITTING135732120
Xcite®+ gun 240B VX24 KHVLP AIRCAP W/O SWIVEL FITTING135732220
Xcite®+ gun 400B VX24 KHVLP AIRCAP & SWIVEL FITTING135732400
Xcite®+ gun 120B VX24 KHVLP AIRCAP & SWIVEL FITTING135732100
DesignationPart number
SWIVEL FITTING NG22 500B F1/2'' JIC M1/4NPS129732435
SWIVEL FITTING NG22 500BAR MF1/2" JIC129732425
Straight extension 400 mm length075810010
Textile hose Ø3.2 FF1/2'' JIC 240B 0.6M with spring050220061
Textile hose Ø3.2 FF1/2'' JIC 240B 1M with spring050220101
